DA-FDB-16G-PA-12 Fiber Optic Distribution Box

Name: DA-FDB-16G-PA-12 Fiber Optic Distribution Box
Brand: Dawnergy Technologies(Shanghai) Co., Ltd.
SKU: DA-FDB-16G-PA-12
Price: 60.60 USD
Availability: InStock

ブランド名	Dawnergy
証明	CE/FCC/RoHS/ISO9001
Model Number	DA-FDB-16G-PA-12

プロダクト細部

Function:

FTTH FTTX System

Splice tray capacity:

16 Cores

Ports:

8 Ports/16 Ports

Dimension (mm):

316*250*126

Max. Splice tray:

1pc

ハイライト:

DA-FDB-16G-PA-12 Fiber Optic Distribution Box

8 Ports Fiber Optic Distribution Box

支払及び船積みの言葉

Minimum Order Quantity

1000

Packaging Details

Carton/Pallet

Delivery Time

7-14 Day

Payment Terms

D/A,L/C,D/P,T/T

製品説明

DA-FDB-16G-PA-12 Fiber Optic Distribution Box

Product Overview

Dawnergy's DA-FDB-16G-PA-12 fiber optic distribution box serves as a termination point for feeder cables to connect with drop cables in FTTx communication network systems. This unit enables fiber splicing, splitting, and distribution while providing solid protection and management for FTTx network infrastructure.

Key Specifications

Attribute	Value
Function	FTTH FTTX System
Splice tray capacity	16 Cores
Ports	8 Ports/16 Ports
Dimension (mm)	316×250×126
Max. Splice tray	1pc

Technical Features

Constructed from high-quality engineering plastic with excellent strength
IP65 Protection Level rating
Easy-open design with superior waterproof performance for outdoor environments
Double-page design simplifies installation and maintenance with separated fusion and termination areas
Drop leaf accommodates 1×8 or 1×16 mini-PLC splitter installation

Primary Application

FTTH Solutions

Environmental Specifications

Operating temperature range: -40℃ to +85℃
Relative humidity: ≤85% at +30℃
Atmospheric pressure: 70KPa to 106Kpa

Thunder-Proof Technical Data

Insulation resistance: ≥2 MΩ/500V(DC) between grounding device and metal parts
Voltage resistance: ≥3000V(DC)/min between grounding device and box metal parts (no puncture/flashover)

Detailed Specifications

Material	Protection Level	Size (mm)	Max Tray Capacity	Suitable PLC Splitter Type	Cable Ports
PP+GF	IP65	305×216×107	16f splicers and 16pcs SC adapters	2pcs 1×8 or 1pc 1×16 mini type PLC	4 ports for main cable (max 12mm each), 16 ports for drop cable (3mm or 3×2mm diameter)

Ordering Information

DA-FDB-16G-PA-12: Black; PP+GF construction; Includes adapter panel for maximum 16 SC type adapters, 4 main cable ports and 16 drop cable ports; Compatible with 1×8 or 1×16 mini type PLC splitter (PLC splitter not included); Dimensions: 305 × 216 × 107 mm; Wall mounting accessories included.
